4Banger LED Pods: HXB Wide Beam

3 Reviews
Questions?

Brand: Morimoto

B-4B-HXBWIDE-MM

$412.00 Original Price:$515.0020% OFF

PRODUCT OPTIONS

PART #: 1 x BAF011.2, 1 x BAF046



Easy Return

DESCRIPTION

Introducing the Morimoto 4Banger HXB Wide - the ultimate off-road LED lights designed to revolutionize your driving experience! Since 2008, Morimoto has been the go-to choice for lighting upgrades in the automotive aftermarket, consistently delivering unrivaled performance, reliability, and style. Our HXB Wide Beam lights are not just powerful; they're SAE-Compliant, boasting an 80% brightness advantage over the competition. With cutting-edge Osram HX Boost LEDs and precision optics, these lights offer superior width, intensity, and control, making them the ultimate off-road LED fog lights. But it's not just about performance; it's about fitment too. The 4Banger HXB is 30% smaller than alternatives, ensuring an OEM+ fitment with Morimoto's mounting kits, available for popular trucks. For a street-legal fog light, our HXB Wide beam models are SAE J583 compliant. Don't settle for less; upgrade to the Morimoto 4Banger HXB Wide and experience off-road lighting like never before!

FEATURES & BENEFITS

  • Bright & SAE-Compliant: 80% brighter, SAE-Compliant for superior illumination.
  • Precision Control: Dual-axis beam adjustment for optimal lighting.
  • Compact Design: 30% smaller footprint, perfect fit for your vehicle.
  • All-Weather Performance: Ideal for rain, snow, and fog with a yellow-output version.
  • Durable & Reliable: Copper DTP PCB, IP69K standards, built to last.

WHAT’S INCLUDED

  • LED Pods: 2x (One Pair) Morimoto 4Banger HXB Wide (White or Yellow)

  • Hardware: Complete pack (stainless steel)

  • Optional Brackets: 2x Top or Bottom Mounts

  • Optional Wiring: 1x Morimoto Switched Relay Harness or 2x Deutsch DT Pigtails

  • Optional Covers: 2x Rubber Blackout Covers

WARRANTY INFORMATION

This Morimoto product includes a Lifetime limited warranty, serviced and supported by the Morimoto team in Atlanta, GA. This warranty does not cover modifications, alterations, or misuse. For additional information, Click Here.

TECHNICAL SPECIFICATIONS

  • Note: These specifications are per pod / each!

  • Intensity (White): 21,000 Cd (Post Warm-Up) (210lux @ 10m)

  • Intensity (Yellow): 14,700 Cd (Post Warm-Up) (147lux @ 10m)

  • Input: Proprietary Overmolded Deutsch DT 2-Pin

  • Power (stabilized): 42w

  • Current: 3.2A @ 13.5V DC

  • Peak Luminosity (raw): 3,000lm

  • Dimensions: 82mm W, 67mm H, 60mm D

  • Hardware: M6 x 1.0 x 8mm (4Banger to U-Bracket), M10 x 1.5 x 20mm (U-Bracket base)

  • Color: 2700K (Yellow) or 5700K (White)

  • Light Source: 3x Osram HX Boost (5700K)

  • Material: Makrolon LED PC (Lens), Powdercoated Die Cast Aluminum (Housing)

LINE DRAWINGS

COMPATIBILITY

  • Universal: With Included U Brackets

COMPLIANCE

Wide beam photometrics are SAE F 20 compliant (HXB Report)(NCS Report)

Off-Road Reinvented: Since 2008, Morimoto has been building the best lighting upgrades for the automotive aftermarket... Consistently turning out products packed with more performance, reliability, and best in-class fitment & style. As a new player in the off-road game, we have embraced that philosophy big time, pumped up the Redbull intake, and now it's time for the old competition to rethink their strategy. The brand new, patent-pending line of 4Banger HXB Off-Road LED lights were completely designed, engineered, and tested in the USA, and everything about them is truly next level.


HXB Wide Beam: Illuminates the ground directly in front of the vehicle. The HXB Optics feature dual axis control. 1) for width, and 2) active hot spot control to project peak intensity right along the top of the beam pattern. The proper vertical gradient and powerful Osram HX Boost LEDs make these the brightest SAE-Compliant fog light pod on the market today (80% brighter than Rigid D-Series SAE Fog and photometrics verified SAE Compliant by Calcoast ITL). The 4Banger HXB Wide beam delivers the best combination of width, intensity, and control -- making it the most effective on and off-road LED fog light in the world.


Form Meets Function: The overall footprint of the 4Banger HXB is approximately 30% smaller than alternatives that offer comparable performance. This allows for an unbeatable OEM+ like fitment when paired with Morimoto's fog light or A-Pillar mounting kits, which are available for today's most popular trucks. Don't be that guy with LED pods bulging out of your bumper.


Performance: There are no "off the shelf" guts inside of a fancy housing here. Every element of the 4Banger HXB is proprietary. LucidShape was used to optimize performance around the most modern, lumen-dense LEDs from Osram. Thermal dynamics have been optimized using SolidWorks. The 4Banger HXB is available with three industry-leading beam patterns to suit every need. Wide/Fog, Spot, and Combo. Patent Pending Design.


All Weather: The white-output version is ideal for all-around visibility. For those who desire optimal output in rain, snow, or fog--the Yellow-output version will slay in shady weather. Morimoto has opted for LEDs that produce yellow light at the origin, which is the most effective way to penetrate through particles in the air without compromising output (Filtering white light through a yellow lens achieves the look, but no actual performance benefit in poor weather).


Reliability: With power comes great responsibility. Extensive effort went into ensuring the reliability of the product. High power means high heat, which is why the 4Banger features a copper DTP (direct thermal path) PCB that maximizes heat-transfer to the radiator, which has been optimized through numerous rounds of thermal analysis. The cast aluminum shell is electroplated before powder coating to withstand flaking. The potted internals, over-molded input wiring, and main gasket are all designed according to IP69K standards for full weather resistance.


Bolt-On: Each set of Morimoto 4Banger LED pods include a set of pedestal mounts for a universal fitment. Morimoto also offers a variety of application-specific mounting bracket kits for fog lights and A-Pillars that make them bolt-on for many of today's most popular trucks. Check out the full lineup for details on what's available for your application.


Street Legality: When aimed properly, the Spot and Combo beams comply with SAE J581 standards for an for auxiliary high beam. If you're looking for a high-performance street-legal LED pod to use as a fog light, both the NCS and HXB Wide beam models are SAE J583 compliant for use as a street legal fog light. (See full test report here) . Some localities require auxiliary lights to be covered for everyday driving. To comply, the optional Blackout Covers are designed to fit all Morimoto 4Banger LED Pods, and are a friction + clip fit that installs with ease, and can be removed in seconds.


Power Up: The Morimoto 4Banger LED Pods have been developed from the ground up to set a new standard in their segment, and the same goes for the optional wire harness. If you want the best, bingo. Not one component on the harness was overlooked for the sake of cost or simplicity. Triple sealed proprietary 4-pin relay with hanger. Proprietary over-molded inline fuse holder with 20A mini fuse. DT06-2S female outputs with dual seals. Stainless steel power and ground terminals. Proprietary M-Spec push button switch with Yellow-LED backlight.
